INTRODUCTION
Overview: Labeling on bottle Front & Back & Neck & Tax Stamp ,With self-adhesvie sticker
SKILT High Speed Labeling Machine Labeling Solution l Advantage
- Ultra-High Speed Performance: Engineered for high-output production, delivering consistent, accurate labeling at speeds often exceeding 12,000 to 30,000+ BPH (bottles per hour)
- Superior Labeling Precision: Utilizes advanced servo-driven rotary technology to ensure flawless, perfectly aligned label application even at maximum speeds.
- Flexible & Rapid Changeover: Modular design allows for quick, tool-less changeover between different bottle sizes and label types, maximizing uptime.
- Robust & Reliable Engineering: Built for continuous 24/7 operation with heavy-duty components and low-maintenance requirements.
- Intelligent Control Systems: Features user-friendly PLC and HMI systems for real-time monitoring, precise, automated troubleshooting, and recipe management.
Suitable labeling Application l Target Industries
- 🍾 Beverage & Brewery: High-volume water, carbonated soft drinks, juices, beers, and spirits.
- 🧴 Personal Care & Cosmetics: Shampoos, body washes, lotions, and shaped cosmetic containers.
- 🧪 Pharmaceuticals & Healthcare: Syrups, vaccine vials, medicine bottles, and supplement jars.
- 🥫 Food & Condiments: Sauces, oils, canned foods, snacks, and glass jars.
- 🛢️ Household & Chemical: Detergents, motor oils, agrochemicals, and large plastic jugs.
Key Application Scenarios
- ⚡ Ultra-High-Yield Production: Mass packaging lines requiring outputs from 12,000 to 30,000+ BPH.
- 🌀 Complex & Shaped Bottles: Flawless labeling on round, square, oval, conical, or customized irregular bottles.
- 🏷️ Multi-Label Combination: Simultaneous application of body, neck, back, or tamper-evident top labels.
- ✨ Premium Aesthetics: Bubble-free, wrinkle-free application of transparent labels or precise cold-glue paper labeling.
- 🔍 Orientation & Positioning: Exact alignment using mechanical, optical, or vision-sensor bottle tracking.
CONFIGURATION
| No | Name | Brand |
|---|---|---|
| 1 | PLC control system | DELTA |
| 2 | Touch-screen | DELTA |
| 3 | Servo motor | DELTA |
| 4 | Servo Drive | DELTA |
| 5 | Servo encoder cable | DELTA |
| 6 | Extended module 1 | DELTA |
| 7 | Extended module 2 | DELTA |
| 8 | Servo power cable | DELTA |
PARAMETER
| Model |
XTHZ600-8S |
| Lock and press bottle heads | 8heads |
| Labeling heads | 1set/2sets/3sets |
| Suitable label size | H: 15-150mm，L:20- 300mm |
| Suitable bottle size | can customized depends on bottle size |
| Yield（pcs/min） |
12000-30000 P/H( can adjustable ) |
| Voltage | 110V/220V/380V/50HZ |
| Machine size | 2400×1700×2080mm |
OPTIONAL
1. Printer device
Printing the date and batch number on the labels .
SERVICE
① Machine with two years warranty；
② Supply operation training for client workers ；
③ If with quality problem, provide technical support and supply wearing parts timely .
④ Range experienced engineer come to client company for installation；
